Large Format Roll Paper Roll To Roll Printing And Flatbed Printing 2 in 1 Multifunction Single Pass Carton Box Printer

Product name : Roll to roll printing and flatbed printing 2 in 1 single pass printer
Brand : Sunthinks
Printer Type : Single pass multifunction packaging printer
Printhead : 2 pcs A4 Pagewide printheads
Ink Type : Pigment ink & Dye ink
Operating System : PLC
Power : 5.0kw
Printing Speed : 30m/min
Printing Size : 1~430mm
Max Material thickness : 80mm
Printer Size(L*W*H) : 2650mm*2250mm*1650mm
Goss Weight : 980kg
Application : Paper rolls,corrugated carton boxes,kratf bags, pizza boxes, wooden boards, etc.

Contact Us

Sunthinks 430mm Roll To Roll Single Pass Printer With 2 Printheads


Product Name
Single pass carton printer/package printer
Brand
Sunthinks
Application
Corrugated cartons，paper boxes/bags, pizza boxes, rolls, wallpaper, drawing boards, wooden boards, etc.
Colors
C/M/Y/K
Ink
Dye & Pigment
Printhead model
A4 pagewide printhead
Printhead quantity
1 pcs
2 pcs
3 pcs
4 pcs
5 pcs
6 pcs
Printing width
215mm
430mm
645mm
860mm
1075mm
1290mm
Printer model
SC215
SC430
SC645
SC860
SC1075
SC1290
Max material width
1200mm
Material thickness
Max 150mm
Print speed
30m/min
Resolution
1200dpi
Product size
2700*2530*1500mm
Auto feeder
Optional
Customized service
Provide
